RO EDI System for Ultrapure Water
An RO EDI system for ultrapure water uses reverse osmosis for bulk ion removal and electrodeionization for the final polish. RO rejects 95–99% of dissolved solids at 150–600 psi. EDI then lifts resistivity above 18 MΩ·cm without acid or caustic. Plants that need ultrapure water run both stages, not one of them.
What Are RO and EDI Water Treatment Systems?
RO and EDI answer different jobs in one purification train. Reverse osmosis uses semi-permeable membranes at 150–600 psi and rejects 95–99% of dissolved ions, organics and suspended particles. On brackish feeds we size, permeate sits around 10–100 µS/cm only after hardness and silt are in range. The shorthand ro y edi t or is this same paired train, not a third process.
Electrodeionization is continuous deionization for water that is already pure. Ion-exchange resins sit between anion- and cation-selective membranes, and a direct-current field pulls the remaining ions out. The electric field continuously splits water into H⁺ and OH⁻ ions, regenerating the resins in place. No acid tank and no caustic tank sit on this stage.
EDI cannot run on raw water. It requires RO permeate with typically less than 25 ppm TDS and less than 1 mg/L total organic carbon (TOC) to protect the modules and hold product resistivity above 18 MΩ·cm. RO handles bulk reduction. EDI handles the final polish.
How Reverse Osmosis Works in Industrial Applications
Industrial RO rejects over 95% of monovalent ions such as Na⁺ and Cl⁻, and more than 98% of divalent ions such as Ca²⁺ and SO₄²⁻. Single-pass recovery typically lands at 75%. Concentrate recycle pushes system recovery up to 95%, which most plants we size for run at the upper end to minimize wastewater.
Operating pressure sits between 200–600 psi, scaled to feed salinity and target flux. The wider 150–600 psi band still covers light brackish duty at the low end. Membrane fouling from organics, silica and hardness scaling is the main reliability risk, so pretreatment with antiscalant dosing, multi-media filters or ultrafiltration is standard.
A Silt Density Index (SDI) below 5 in the feed is the usual acceptance threshold for protecting RO membranes and holding membrane life to the typical 3–5 year replacement interval. Cleaning is scheduled every 3–6 months. For project sizing and skid details, see our industrial RO water treatment system with 95% recovery.
How EDI Delivers Ultrapure Water Without Chemicals
EDI modules consistently deliver product water above 18 MΩ·cm resistivity, the purity benchmark for semiconductor rinse, pharmaceutical Water for Injection (WFI) and high-pressure boiler feed. The key operational difference versus mixed-bed ion exchange is continuous self-regeneration. An applied DC field continuously splits water inside the cell to regenerate the ion-exchange resins, so there is no acid or caustic cycle, no neutralization step and no hazardous chemical storage on site.
Recovery runs 90–95% with less than 5% blowdown. Feedwater quality must be controlled tightly, which usually means a degasifier or a second-pass RO stage to strip CO₂ and drop dissolved gas low enough for the EDI current to work. Energy draw is modest at 0.5–1.5 kWh/m³, and the hardware footprint is small. A single module can produce roughly 50 m³/h in about 1.5 m² of floor space.
Module service life is typically 5–10 years, with no moving parts inside the stack. Most plants we size for only see that life when TOC and hardness stay inside the feed gate every day, not just at commissioning. If you need an engineered skid around this stage, the EDI Electrodeionization System product page lists standard flow rates and feed specs.
RO vs EDI: Side-by-Side Technical Comparison
RO and EDI are not interchangeable stages, because RO removes 95–99% of dissolved solids and EDI polishes what remains. EDI is the chemical-free step that pushes resistivity above 18 MΩ·cm, while RO works at 200–600 psi. Pressure, energy and maintenance follow those roles, and the table below keeps every original comparison value.
| Parameter | Reverse Osmosis (RO) | Electrodeionization (EDI) |
|---|---|---|
| Primary Function | Bulk dissolved solids removal (pre-treatment) | Final polishing for ultrapure water |
| Removal Efficiency | 95–99% of TDS, organics, particles | >99.9% of residual ions (after RO) |
| Purity Output (Typical) | Permeate ~10–100 µS/cm | Product >18 MΩ·cm (~0.055 µS/cm) |
| Feedwater Requirement | Raw or pre-filtered water (SDI <5) | RO permeate (<25 ppm TDS, <1 mg/L TOC) |
| Operational Pressure | 200–600 psi | 20–100 psi (low pressure) |
| Energy Consumption | ~2–4 kWh/m³ | ~0.5–1.5 kWh/m³ (depending on flow/TDS) |
| Chemical Consumption | Antiscalants, membrane cleaning chemicals | Zero chemicals for regeneration |
| Regeneration Method | Membrane cleaning (chemical) | Continuous electrical self-regeneration |
| Maintenance | Membrane cleaning every 3–6 months, membrane replacement every 3–5 years | Minimal service, no moving parts, module replacement every 5–10 years |
| Water Recovery Rate | 75–95% | 90–95% |
RO's energy draw comes from the high-pressure pump pushing past osmotic pressure, so power use scales with feed salinity and recovery target. EDI's energy draw comes from DC current through the stack, so power use scales with inlet conductivity and flow. RO needs antiscalant dosing and periodic chemical cleans. EDI needs neither.
Most plants we size for boiler makeup spend the power budget on the RO pump, not on the EDI rectifier. The combined RO+EDI train, configured as an industrial RO water treatment system with 95% recovery feeding an EDI polisher, is the standard answer for ultrapure specs. Cost, efficiency and compliance figures for the same choice are tabulated in RO vs EDI Water Treatment: 2026 Engineering Comparison with Costs, Eff.
EDI Polishing Stage after RO Permeate
The EDI polishing stage after RO permeate takes water at about 10–100 µS/cm and is sized to deliver resistivity above 18 MΩ·cm. Operating pressure on the stack is 20–100 psi, which is low compared with the RO pump. Feed must stay under 25 ppm TDS and under 1 mg/L TOC, or the resins foul and the 18 MΩ·cm floor slips. Removal of the ions that remain after RO is above 99.9% when that feed gate holds.
Dissolved CO₂ and bicarbonate still ride through a single RO pass and load the EDI current. A degasifier or a second-pass RO stage is the usual strip. Most plants we size for choose the degasser when free CO₂ is the only outlier and the second pass when conductivity is also high. Hardness does not belong in this stage, so fix it in pretreatment before you blame the module.
This article's operating floor remains resistivity above 18 MΩ·cm. According to ASTM D5127-13(2018) Table 1, online resistivity at 25°C is 18.1 for Type E-1 water at line widths of 1.0–0.5 μm, and 18.2 for Types E-1.1, E-1.2 and E-1.3. Those tighter types cover lines from 0.35–0.25 μm down to 0.065–0.032 μm. TOC caps in the same table are 5 µg/L, 2 µg/L and 1 µg/L as the line gets finer.
The guide names continuous electrodeionization with reverse osmosis as a desalination route, and the limits apply at the point of distribution. Impurity caps are maximums, while resistivity is the minimum. Most plants we size for fabs read resistivity on the loop return, not only at the skid outlet, because the ASTM numbers are point-of-distribution values.
RO Followed by EDI Pharmaceutical WFI
RO followed by EDI for pharmaceutical WFI is accepted when the process matches distillation on chemical and microbial removal and the monograph tests pass. According to the USP Water for Injection monograph, WFI is purified by distillation or by a purification process equivalent or superior to distillation. That text has been official since 1 November 2018 and was still official on 17 February 2025. Bacterial endotoxins must be less than 0.25 USP Endotoxin Unit/mL.
Bulk water must meet conductivity in USP chapter 645 and total organic carbon in USP chapter 643. Source water has to comply with the US EPA National Primary Drinking Water Regulations, or with EU or Japan drinking-water rules, or with the WHO Guidelines for Drinking Water Quality. The monograph allows no added substance. Passing a resistivity above 18 MΩ·cm does not by itself prove the endotoxin limit, because those chapters test conductivity and TOC rather than an 18 MΩ·cm floor.
When is RO plus EDI required for WFI?
RO plus EDI is required for WFI when the plant drops distillation and must still meet endotoxin, conductivity and TOC limits on a validated membrane train. According to WHO Technical Report Series No. 1033, Annex 3 (2021), bulk purified water may be prepared by ion exchange, reverse osmosis, RO with electrodeionization, ultrafiltration or a combination, starting from drinking-water. The same annex allows bulk water for injections by distillation or by means other than distillation. Electrodeionization, ultrafiltration, degasification and related steps may be used with single-pass or double-pass RO, and WHO points to Technical Report Series No. 1025, Annex 3 (2020), for the full non-distillation method.
RO EDI Water Recovery Rate Industrial
The RO EDI water recovery rate on an industrial train is set by the RO stage, not by the EDI module. Single-pass RO recovery typically lands at 75%, so roughly 25% of the feed goes to drain as concentrate and needs a disposal route. Concentrate recycle can raise RO recovery to 95%, and most plants we size for sit near that top end to cut wastewater. EDI recovery stays at 90–95% with less than 5% blowdown, so the polisher rarely sets the site water balance.
Power splits the same way. RO draws about 2–4 kWh/m³ at 200–600 psi, and the draw rises with salinity and with the recovery target. EDI draws about 0.5–1.5 kWh/m³ from stack current. Chemical cost sits on the RO side, as antiscalant plus cleans every 3–6 months and membranes every 3–5 years.
EDI regeneration chemicals stay at zero, and the stack is typically replaced every 5–10 years. That chemical gap is why a hybrid train is often quoted at roughly 30–50% lower operating cost than mixed-bed ion exchange.
What should you check before buying?
Check feed quality, the product spec, recovery and the EDI inlet gate before you buy the train. Use this list on the data sheet, not as a brochure score.
- Feed TDS, hardness, silica, TOC, SDI and free CO₂, including the seasonal high.
- Product spec: resistivity target, TOC, and endotoxin below 0.25 USP Endotoxin Unit/mL if the grade is WFI.
- RO recovery aim, 75% on a single pass or up to 95% with recycle, plus a reject route for the roughly 25% concentrate at the low recovery.
- EDI feed gate: less than 25 ppm TDS and less than 1 mg/L TOC, with CO₂ stripped by a degasser or a second RO pass.
- Inline TOC, conductivity, pressure, flow and temperature on the purified-water or WFI loop, which WHO TRS 1033 calls for.
- Replacement clock: RO membranes on a 3–5 year interval, EDI modules on a 5–10 year interval, RO cleans every 3–6 months.
- Sanitization method, and a test that shows any chemical agent is gone before water returns to use.
When to Use RO, EDI, or RO+EDI Together
The choice among RO, EDI or RO+EDI comes from the product water spec, not from preference. RO alone covers food and beverage process water, cooling-tower makeup and standard boiler feed where ultrapure resistivity is not required. RO+EDI is the right answer when product resistivity must exceed 15 MΩ·cm. That covers pharmaceutical WFI and Purified Water (PW) loops under USP, semiconductor rinse water and high-pressure power-plant boiler feed.
EDI cannot tolerate high TOC above about 1 mg/L or significant hardness, so RO pretreatment is non-negotiable in front of any EDI stack. Compared with traditional mixed-bed ion exchange, hybrid RO+EDI cuts operating costs roughly 30–50% by eliminating acid and caustic regeneration and the associated waste neutralization. For plants that want pretreatment and polishing on one skid, the all-in-one water purification system with RO-ready pretreatment is worth a look alongside standalone RO skids. If you only need the polishing stage on an existing RO loop, the EDI Electrodeionization System pages show standard flow rates and feedwater envelopes.
Who this comparison is for
Process engineers and procurement managers sizing a new ultrapure water loop, or auditing an existing mixed-bed ion-exchange system that is due for replacement, are the readers this comparison serves. If you are sizing for a semiconductor fab, a pharma WFI skid or a high-pressure boiler, plan for RO+EDI from day one and budget the pretreatment around it. If your spec only needs softened or demineralized water under 10 µS/cm, RO alone is usually enough and EDI is an extra skid.
Who should look elsewhere
Plants that need only softened utility water, or demineralized water under 10 µS/cm, should not buy an EDI stack for that spec. Packaged sterile water meant for direct injection is a different product. The USP monograph says packaged Water for Injection is not intended for direct parenteral administration. A bulk RO and EDI skid does not replace sterile fill or a validated hot distribution loop.
Next step
Send us your feed analysis (TDS, hardness, TOC, silica, free CO₂) and your target resistivity and recovery, and we will return a sized RO+EDI train with estimated energy, recovery and chemical use. Request a sized RO+EDI quotation with your feedwater data attached.
Frequently Asked Questions
What are the downsides of RO water?
RO sends roughly 25% of the feed to drain as concentrate at a typical 75% recovery, so that reject stream needs a disposal route. Pretreatment must hold the Silt Density Index below 5, or organics, silica and hardness foul the sheet. Cleaning then crowds the 3–6 month window, and membrane life slips off the 3–5 year mark. RO also strips dissolved minerals, which suits most industrial loops and is a separate question for potable duty.
What is EDI in RO?
EDI is not part of the RO membrane. It is a separate downstream polishing stage that runs on RO permeate. RO drops the water to permeate levels around 10–100 µS/cm. EDI then pushes resistivity past 18 MΩ·cm with ion-exchange resins and a DC field, with no chemical regeneration, as long as feed stays below 25 ppm TDS and below 1 mg/L TOC.
Can EDI replace RO?
No. EDI cannot replace RO, because the stack needs RO permeate quality at its inlet, typically below 25 ppm TDS and below 1 mg/L TOC. On raw or high-salinity water, EDI modules foul fast and lose performance. RO is the only practical bulk-removal step in front of EDI in an industrial ultrapure train.
Do RO and EDI systems require regeneration?
RO membranes are not chemically regenerated. They are cleaned with specialized chemicals on a 3–6 month cycle and replaced every 3–5 years. EDI stacks regenerate themselves continuously through the DC field splitting water inside the module. There is no separate acid or caustic cycle and no regeneration downtime on the EDI stage.
Which is better for pharmaceutical WFI and semiconductor rinse, RO or EDI?
For pharmaceutical Water for Injection under USP, and for semiconductor rinse water, the answer is RO followed by EDI, not either stage alone. RO handles bulk ion and organic reduction to RO permeate quality. EDI polishes that water to resistivity above 18 MΩ·cm and the TOC stability these specs need, without mixed-bed chemical handling. ASTM D5127-13(2018) lists online resistivity at 25°C of 18.2 for the tighter semiconductor grades, which is why the EDI floor stays above 18 MΩ·cm.
